Progressive Cavity Metering

Metering and Mixing System for encapsulation applications

Compact 2-component, servo driven Progressive Cavity metering unit suitable for processing the smallest metering volume in precision applications requiring the necessity of processing abrasive or shear-sensitive materials at the highest accuracy. For Low- to medium viscous materials with functional fillers.

Compact and lightweight, ideal for robot mounting for high accuracy of the smallest volumes.

Contact Us To Discuss A Conti-Pro Solution

PCP Metering Valves:  (Progressive Cavity Metering Valves)

Brands: ContiPro / VarioPro / ViscoPro / Accura

For Perfect Metering and Dosing Applications:

PCP Metering Valves have been designed for precise metering/dosing of fluids and pastes and are especially suitable for abrasive media and for Metering/Dosing and dispensing proportional to speed. Accuracy and repeatability is ± 1%.

Precise - Variable - High Repeat Accuracy - Clean

PCP Metering Valve is based on the volumetric principle of an endless (eccentric) piston whereas the core components rotor and stator form a perfectly sealed metering chamber. The eccentric movement of the rotor allows for a low-shear motion of the medium from one chamber to the next chamber without compressing the media. The metering chamber is optimally designed for dispensing liquids and pastes containing fillers.

By combining the principle of the eccentric screw pump with precision control of the metering time and rotor speed, the new PCP Metering / Dosing Valves supports the proportional volume to speed metering application of various lubricant / adhesives / epoxies / thermal paste in quantities with the highest precision and repeatable accuracy.

Since the motor controller can also turn the rotor backward, this PCP Metering / Dosing Valves, guarantee clean metering without dripping. Precise, reliable and consistent volumetric metering is possible thanks to the adjustable application speed and rotor rotation.

Advantages:

• Suitable for variable metering of low to high-viscosity and abrasive materials.
• Pressure resistant up to 35 bar - the rotor and stator form a metering chamber with optimum seal
• Integrated control unit and release button for manual operation
• Adjustable application speed thanks to variable speed drive.
• Metering volume proportionate to rotation speed
• High metering and repeat accuracy
• Broad range of applications (robotics, servo technology and manual workstations/assembly stations)
• Point and bead application
• Flexible metering volume - continuously variable metering quantity
• No dripping (snuff-back)
• Pulsation-free

Advantages

With improvement adaptation of the rotor and stator geometries, PCP Metering Valves have been designed to be significantly smaller than earlier systems. This makes the progressive cavity pump particularly well-suited for use with small metering robots, since the centrifugal forces in fast, dynamic traverse paths cannot influence the pump.

Because of the design this self-contained metering device is able to accurately dispense liquids and pastes with up to 60% filler content, whereby the external integration of the metering pump is made possible independently of pressure regulators. The metering quantity can be set to be absolutely linear; the standard deviation of metering accuracy as well as repeatability is ± 1% or less.

More Advantages

• High Metering Accuracy, ± 1% Volumetric
• High Repeatability, ± 1%
• Continuous Metering / Dosing
• Speed Proportional Transfer
• Valveless Closed System
• Handles Abrasive Media
• Low Pulsation And Shear

Since our company was established, we have supplied our customers with precision metering and dosing components, but have also manufactured and integrated high-end automation and metering and dosing application systems that are designed to address particular application processes.

In this, we draw on various module configuration platforms to provided complete turnkey designs such as material feeding supply, material preparation, Mixing heads, positive displacement dispensers, chemical proportioning plants, adhesive and paint coating systems, Metering / Dosing pumps and controls.

Our core competency lies in developing application solutions to solve challenges in metering, mixing, dosing applications Our goal is to provide the most advanced process solution that is extremely accurate, extremely reliable and user-friendly.

Industries

• Aerospace
• Automotive
• Electronics
• Cosmetics
• Pharmaceutical
• Medical technology

Typical Applications

• Metering / Dosing of Filling Compounds
• Coating of Electronic Components
• Protective Coating of Printed Circuit Boards
• Application of Epoxy Resin Adhesives
• Bead Dispensing
• Sealing
• Metering and Dosing
• Filling

Technical Data – PCP metering valve / Art. no.:

Displacement: ml/rev.	0.01 to 4.00
Direction of Rotation	CW / CCW
Speed of Rotation:	1 – 400 rpm
Inlet Port (Suction)	1/8 to 1/4
Outlet Port: (Pressure)	5 mm to 1/4”
Outlet Pressure	10 – 35 Bar
